The intelligent logistics box applies the advanced internet of things technology, positioning technology, communication technology, national security encryption technology, micro-motor control technology, heat preservation and insulation technology to achieve the whole monitoring of the transportation process, so as to achieve the purpose of anti-theft, anti-transfer, anti-loss, anti-damage, guarantee the safety of goods, quality traceability. It can be used in express transportation, valuables transportation, logistics transportation, confidential document transportation, cold chain transportation, fresh transportation, medical and medical drugs transportation and sample inspection transportation. intelligent logistics box intelligent logistics box
Product Charactersintelligent logistics box intelligent logistics box intelligent logistics box
Imported lock cylinder, smooth machinery and solid structure.intelligent logistics box
Dynamic password, one code one time, multiple types and multiple permission to unlock.intelligent logistics box
Financial grade data encryption mechanism, anti-interception, anti-crack.intelligent logistics box
Real-time upload data and status information, big capacity local storage.
Big data platform, real-time update data, historical data query and all-round monitoring.
Industrial grade special material.intelligent logistics box intelligent logistics box intelligent logistics box
Real-time positioning: BD/ GPS dual-mode accurate positioning, LBS auxiliary positioning, path planning and electronic fence functions.intelligent logistics box intelligent logistics box intelligent logistics box
Real-time communication: real-time data reporting through GSM/ GPRS communication technology.
Multiple unlock methods: remote unlock, mobile phone unlock and password unlock.intelligent logistics box
Alarm: unpack alarm, low electric quantity alarm and other alarms.intelligent logistics box
Data storage: achieve break point continuous transmission and call at any time.intelligent logistics box
Strong battery endurance time: the data uploading interval is 1 minute, open twice one day, the battery endurance time is 10 days. The remaining electric quantity is 10%, at this time all functions can still operate normally.intelligent logistics box
Big capacity: effective volume up to 22L, can store a large number of objects.intelligent logistics box
Box body material selection of ABS plastic material with tough and solid features.intelligent logistics box
Product Parameters
| ITEMS | SPECIFICATIONS | |
| Basic Parameters | Working Voltage And Electricity | 5V DC; 40mA |
| Working Temperature | -20℃~49℃ | |
| Working Humidity | Relative humidity is not greater than 85% | |
| Working Environment | Atmospheric pressure 86KPa~106KPa, clean air, no strong electromagnetic field, no strong shock, no corrosive gas and substance | |
| Specification Measurement | Box Body Measurement | Outside: L 486mm * W 419mm * H 203mm; Inside: L 436mm * W 281mm * H 190mm |
| Effective Volume | 23L | |
| Weight | 6.25KG | |
| Battery Capacity | 17500mAH | |
| Charging Port | Type-C interface | |
| Camera Pixel (optional) | 100W | |
| Performance | Battery Endurance Time | 5~30 days (determined by the time interval of the setting positioning updates) |
| Charging Time | 6H (5V/ 2A) | |
