ProductParameters and Functions Introduction
Product Series	PN-201 NFC Passive Intelligent Padlock	Product Model	PN-201NFC
Material	Lock body: zinc alloy Lock beam: alloy steel	Dimension	85*50*19mm
Lock Beam Tensile Force	400kg	Weight	142g
Function Unlock	NFC sensing unlock	Unlock Method	Pop out the shackle automatically
Waterproof Level	IP55	Color	Black
NFCFunction	Through the mobile phone NFC function, wireless transmission of power supply and transmission of unlock instruction can achieve the unlock function of mobile phone APP. When using for the first time, it needs to look for the best signal position of mobile phone NFC to convenient later periodnormal use and without causing incomplete power supply and unable to unlock	APP Function	Based on mobile phone NFC torealizethe unlock/ lock function and providethe function of query records of unlock/ lock information.
UserRegistrationBinding	Turn on the NFC function of the mobile phone and read the product information by placing the sensor area of the mobile phone close to the lock surface. After reading, pleaseclickthe add button	SensingMethod	Click unlock through the mobile phone APP, and then move the NFC signal position of the mobile phone close to the lock surface for sensing unlock
Battery	No power supply	EmergencyPowerSupply	No USB
Power Consumption	Standby≤0uA, working≤80mA	Motor Model	M10Micromotor, opening times testing is more than 200,000 times
Working Temperature	-20℃～60℃	RelativeHumidity	20%-80%
